CỜ LÊ MIỆNG, VÒNG STAHLWILLE 13 MM-613500_13

Giới thiệu CỜ LÊ MIỆNG, VÒNG STAHLWILLE 13 MM-613500_13

Version:

Sturdy compact one-armed torque wrench, adjustable to scale and self-triggering.
The accuracy is sustained for many thousands of operations, because high quality material is used for all wearing parts with stressed parts loaded only briefly on each occasion.
Body and handle are of sturdy square section.
Scales adjustable.
Anti-clockwise tightening by pushing through the drive shankWithout any plug-in head (basic model); see No.
657582 − 657950 for suitable plug-in heads.

Units of measure:

Nm, lbfft.

Advantage:

Ergonomically shaped two-component handle, resistant to aggressive liquids such as fuel, Skydrol etc.
The adjustment scale is placed behind a sight glass for protection against dirt and damage.

Quick, precise, and reliable setting:

Pull the setting knob, “Twist” to set the desired value and “Press” to save it.
Setting knob moves easily since there is no spring pressure to be overcome.

Function:

If the set value is reached while using the wrench, the wrench triggers giving a “signal” (acoustic and perceptible) and is then immediately ready for use again.

Application:

Since the set torque can be varied, it is ideal for repairs and short series production.

Standard:

Tested to DIN EN ISO 6789.

Note:

The guaranteed measuring accuracy of the torque is achieved only once the torque range has been calibrated to DIN EN ISO 6789.
-----------


maximum torque

200 Nm



Direction of tightening

For right and left-hand tightening



Torque measuring accuracy

±3 %



Exchangeable tool

Plug-in head



Test certificate

Manufacturer’s test certificate



Calibration

O1



Series

MANOSKOP 730N



Overall length L

467 mm



Torque range

40 Nm - 200 Nm



Torque range

30 lbfft - 150 lbfft



Scale graduation, 1 graduation =

1 Nm



Weight

1,264 g



Adjusted reference dimension on the torque wrench [l₂]

25 mm



Socket for plug-in head

14×18 mm



Display

analogue



Release signalling

akustisk; haptisk



Trigger principle

mechanical short-travel release



Connection format

for plug-in heads (rectangular socket)



Measurement technology

mechanical



Data can be recorded

no



Setting the trigger value

with adjustment scale



Feedback

triggering



Reversible reading

Nm; lbfft



Measurement process

Torque



Adjustable trigger value

adjustable



Standard

DIN EN ISO 6789



Lever length without plug-in head [l₁]

424 mm



Lever length including factory calibration reference dimension [l₃]

449 mm



Type of product

Torque Wrench
